microsoft / 3dtelecommunications

3D Telecommunications project utilizing Holoportation technology to provide live volumetric capture. Used in one case to increase the reach of specialized medicine.

3D Telecommunications

This is the open source repository for the 3D Telecommunications system created by Microsoft Research Special Projects Group and used in the 3D Telemedicine application: https://www.microsoft.com/en-us/research/project/3d-telemedicine/

System Requirements

The typical system layout for 3D Telemedicine is to have one machine running Fusion, and a separate machine running Render and Viewer. The pods all run their own copy of the K4AToFusion code and should be networked into the same network as Fusion. Control panel can be run on the Fusion PC, the Render PC, or a separate PC or tablet.

Minimum Operating Requirements (Fusion)

• Windows 11
• CUDA 11.7
• Nvidia GPU 2080Ti or larger
• 10 Gigabit ethernet adapter
• OpenCV 4.5.4

We use OpenCV with CUDA libraries. This means you cannot just use the binaries available directly on the website, although there are typically additional sites that provide OpenCV with CUDA built in.Currently our project requires the opencv_contrib folder also be checked out of GIT and compiled as part of OpenCV. We hope to remove this dependency in the future.

Minimum Operating Requirements (Render, Viewer)

• Windows 11
• CUDA 11.7
• Nvidia GPU 2080Ti or larger
• 10 Gigabit ethernet adapter

Minimum Operating Requirements (Control Panel)

• Windows 11
• 1 Gigabit ethernet adapter

Minimum Operating Requirements (K4AToFusion, K4ARecorder)

• Azure Kinect SDK
• Nvidia Jetson Nano

Building from Source

3rd Party Components (Windows)

This system relies on the following open-source 3rd party components:

Component	Version	Link
boost	1.72.0	https://www.boost.org/users/download/
ceres-solver	1.9.0	https://ceres-solver.googlesource.com/ceres-solver
cppzmq	4.7.1	https://github.com/zeromq/cppzmq
freeglut	3.0.0	https://freeglut.sourceforge.net/
glew	1.7.0	http://glew.sourceforge.net/
libjpeg	9c	https://github.com/winlibs/libjpeg
jsoncpp	1.8.1	https://github.com/open-source-parsers/jsoncpp
libzmq	4.2.0	https://github.com/zeromq/libzmq
LZ4	1.8.3	https://github.com/lz4/lz4
oglplus	0.72.0	https://github.com/matus-chochlik/oglplus
OpenCV	4.5.4 (CUDA)	https://github.com/opencv/opencv
qhull	2011.1	http://www.qhull.org
suitesparse-metis	1.5.0	https://github.com/jlblancoc/suitesparse-metis-for-windows.git
VXL	2.0.2	https://github.com/vxl/vxl.git
xerces	3.1.1	https://github.com/apache/xerces-c/
zlib	1.2.5	https://www.zlib.net/
CUDA	11.7	https://developer.nvidia.com/cuda-11-7-1-download-archive?
Visual Studio	2019	https://visualstudio.microsoft.com/downloads/

The default configuration expects these dependencies to be placed in a Dependencies\ folder inside the root of the repo. You can change this location by modifying the definition of Peabody_Dependency_Dir in PeabodyConfigurationMacros.props, or modifying only a specific component's location in its Peabody.x64.[componentName].props file.

3rd Party Components (Linux)

Component	Version	Link
libk4a	1.4.1	https://learn.microsoft.com/en-us/azure/kinect-dk/sensor-sdk-download
ZeroMQ	4.3.4	https://github.com/zeromq/libzmq/
CppZMQ		https://github.com/zeromq/cppzmq
OpenCV	4.5.4 (CUDA)	https://github.com/opencv/opencv
CUDA	11.x	Bundled in Jetpack OS Image

System Components

This repo includes source code to compile the following systems:

Fusion

Fusion is the main component that creates a watertight, volumetric mesh in real time from any number of RGB+D streams. The textured volume and raw (or jpeg compressed) RGB images are transmitted to any number of render clients.
It is based off of the Fusion4D algorithm https://www.microsoft.com/en-us/research/publication/fusion4d-real-time-performance-capture-challenging-scenes-2/ Fusion is a C++ and CUDA project, and is known to work with CUDA 11.4+. It uses Boost ASIO for transmmitting data.

Render

Render takes a volumetric mesh from the fusion system and textures it with the RGB images provided in the same data stream from fusion, and transmits the textured model over the network to any number of viewer clients.
It is a C# Unity project, and is known to work with Unity 2019.4.14f1 It is also dependent on the C++ Rendering Client DLL for transmitting data. It uses Boost ASIO for transmitting data.

Viewer

Viewer subscribes to a given Render stream and presents the textured 3D model to the user. It provides views of the 3D model and the 2D cameras. It also includes drawing tools and capture tools for manipulating the model. It is a C# Unity project, and is known to work with Unity 2019.4.14f1. It uses Boost ASI for transmitting data.

Control Panel

The control panel software orchestrates all of the components of the 3D Telemedicine system. It provides one interface to start a calibration session, start a broadcast (live) session, modify configuration values, transmit configuration to the various components, monitor status and version of all components in the system, and check for updated components from an Internet-accessible source. It is a C# .Net project that utilizes the zeroMQ networking library for all communication. You will find most other components in the system have a ControlPanelConnector class to handle the communication with the Control Panel.

Calibration Software

The calibration software will take a number of synchronized input mkv videos from cameras in the system (Azure Kinect) and output a calibration file that provides world coordinates of all cameras in the system. It is dependent on the PAI calibration system available at this NuGet repository: It is a C++ project. It uses ZeroMQ for transmitting progress updates to the Control Panel.

K4ARecorder

This is a port of the K4ARecorder provided in the Azure Kinect SDK that integrates it into our system and communicates with the Control Panel. It performs the same functions as K4ARecorder and is dependent on that library. Recorded videos are transmitted from the camera units to the fusion machine via scp.

K4A To Fusion

K4AToFusion is the ingest code that pulls images from an Azure Kinect and transmits them to a Fusion server. It is written to run on an Nvidia Jetson Nano (Linux) It is written in C++ and uses the ZeroMQ library for communication with the Control Panel, and Boost IO libraries for streaming image data.

Azure Kinect Launcher Daemon

Azure Kinect Launcher Daemon is the Linux system daemon that monitors the status of the Kinect-attached Jetson Nanos and communicates with the Control Panel. The Control Panel uses this daemon to launch the K4A To Fusion software, K4ARecorder software (for calibration), check version information, upload new configuration files and software versions, and receive updates about current system and application status. It is written in C++ and uses the ZeroMQ library for communication.

3DTM Launcher Service

3DTM Launcher Service is the Windows service that runs on Fusion and Render machines and communicates with the Control Panel. The Control Panel uses this service to launch Render, Fusion, and the Calibration Software. It also uses this service to check software versions, transmit configuration data and new software versions, and receive updates on current system and application status. It is written in C++ and uses the ZeroMQ library for communication.

Kinect Nano Communicator Service

In certain configurations where the camera system may be on a separate subnet from the control panel, the Kinect Nano Communicator Service can act as a router to route messages from the Azure Kinect Launcher Daemon and K4A To Fusion components of each camera unit up to the control panel on a separate subnet.

Setup [Windows components]

System requirements

The Windows components (Fusion, Render, Viewer, Control Panel, Calibration Software, 3DTM Launcher Service, and Kinect Nano Communicator Service) leverage code implemented using C#, CUDA 11.4+, and Unity. As such, a build agent containing an Nvidia GPU (RTX 2080 or later), Windows 10+ OS, and Unity 2019.4.14f1 is necessary to compile the components.

Component download

Check out the repository to a location of your choice, we'll refer to it as [3dtmroot].

Create the folder for the dependencies, [3dtmroot]\Dependencies.

Download the dependencies and install them into the Dependencies folder.

Build (Fusion)

Fusion is built using the DeformableFusion solution in the DeformableFusion folder of the repository. It should be built in Release, x64 configuration. Debug currently does not compile. The DeformableFusion solution contains a number of helper libraries that will be built first, and the Fusion executable is built as part of the LiveFusionDemo-MultiView project, which is selected as the startup project.

Setup [Linux components]

System requirements

The Linux components (Azure Kinect Launcher Daemon, K4A To Fusion, K4ARecorder) are built for the ARM64 architecture of the Nvidia Jetson Nano. Our build system uses the Ubuntu 18.04 image from the Nvidia Jetson website that includes CUDA. We have only built source code on Nvidia Jetson TX1 using the aforementioned Ubuntu image. The system should compile on newer Nvidia Jetson hardware, so long as the Ubuntu 18.04 image is used for backwards compatibility with existing PODs.

Component download

Check out the repository to a location of your choice, we'll refer to it as [3dtmroot]

Clone the Azure Kinect SDK: https://github.com/microsoft/Azure-Kinect-Sensor-SDK.git

Install the additional required build packages:

• Azure Kinect libraries - https://learn.microsoft.com/en-us/azure/kinect-dk/sensor-sdk-download#linux-installation-instructions
• Ncurses
• SoundIO (required for Azure Kinect)
• Boost - System
• Boost - IO Streams
• ZMQ
• ProcPS
• LZ4
• JSONCpp
• ZeroMQ 4.3.4
• cppzmq
• OpenCV 4.5.4

sudo apt update && sudo apt install -y libk4atools libk4a1.4  libk4a1.4-dev libncurses-dev libsoundio-dev libboost-system-dev libboost-iostreams-dev libzmq3-dev libprocps-dev liblz4-dev libjsoncpp-dev

The system requires zeromq 4.3.4 with drafts enabled, which is not available in the Jetson Ubuntu 18.04 image. So to do this:

ZMQ_VERSION=4.3.4
PREFIX=/usr/local
wget https://github.com/zeromq/libzmq/releases/download/v${ZMQ_VERSION}/zeromq-${ZMQ_VERSION}.tar.gz -O libzmq.tar.gz
tar -xzf libzmq.tar.gz
cd zeromq-${ZMQ_VERSION}
./configure --prefix=${PREFIX} --enable-drafts
make -j && make install

You can install cppzmq from here: https://github.com/zeromq/cppzmq.

You'll also need OpenCV 4.5.5. Here's a great tutorial to get it built on the nano: https://qengineering.eu/install-opencv-4.5-on-jetson-nano.html.

Now set up the paths correctly in the cmakelists.txt.

Build (Linux)

You can build all of the linux projects at the same time by

cd [3dtmroot]
mkdir build
cd build
cmake ..
make
sudo make install

Reminder

You might be tempted to update your build environment to a newer version of Ubuntu or other libraries, but remember that most libraries will be dynamically linked, not bundled in the binary, so they won't run on a Jetson Nano, which only has Ubuntu 18.04 as the latest OS.
